Production Introduction
As an important part of the unmanned packing solution in the process of secondary packaging production line, Automatic Robot Palletizer is a high-speed palletizer which designed and manufactured by high-speed parallel industrial robot technology. It has excellent characteristics such as excellent safety performance, fast moving speed, high positioning accuracy and durability of key components.
Main Features
Robot has powerful operation function and high precision operation, which can realize fast packing, palletizing and disassembling.
In the production line, the robot palletizing for packing, palletizing and disassembling operations can be flexibly arranged, and two or more lines can be palletized simultaneously, which is the ideal choice for palletizing at the end of the production line.
Servo motors, programmable controllers and variable frequency speed controllers adopt first-class products to ensure the reliability and long life of the system hardware.
High-quality hardware and specially designed control software are combined to achieve a high degree of automation of the system. The perfect safety interlocking mechanism can provide protection for equipment and operators.
Our excellent technology, stable and reliable products and perfect services have improved the level of factory automation in an all-round way.
Technical specification
1 | Machine model | ABB IRB460 palletizer | ABB-IRB660 |
2 | Axle | 4 axle | 4 axle |
3 | Max weight of every layer： | 110KG | 250kg |
4 | Arrive distance | 2.4m | 3.15m |
5 | Max weight of every pallet | 1600KG | 1600KG |
6 | Max height of palletizing： | 1750MM（include the pallet） | 1750MM（include the pallet） |
7 | Max dimension of pallet | 1300*1100MM（can be change according to demand） | 1300*1100MM（can be change according to demand） |
8 | Voltage | 3 phase 5 lines，AC 200-600vV/50-60HZ， | 3 phase 5 lines，AC 200-600vV/50-60HZ， |
9 | Power | 3.67KW | 3.2KW |
10 | Air consumption: | 0.3 CBM (0.6-0.8kg) | 0.3 CBM (0.6-0.8kg) |
11 | Dimension of machine | (L)10500MM*(W)6500MM*(H) 3800MM (will be different according the clamp device size ) | (L)10500MM*(W)6500MM*(H)3800MM(will be different according the clamp device size ) |
12 | Weight of machine： | 925KG | 1650KG |
